Place of Origin:
Hunan
Brand Name:
Pinsheng
Model Number:
50160119F
Document:
| Battery Type | LiFePO4 |
| Rated Voltage Range | 51.2V |
| Rated Capacity Range | 150~700AH |
| Max Charge/Discharge Current | 50A/100A |
| Operating Temperature | -15°C~55°C |
| Working Altitude | 0-2000m |
| Waterproof Level | IP20 |
| BMS Communication | CAN |
| Electricity Communication Port | RS485 |
| Cooling Method | Cooling Fans |
| Output Waveform | Pure Sine Wave |
| Switching Time | 10ms |
| Max Efficiency | 98.20% |
| European Efficiency | 97.50% |
| MPPT Efficiency | 99.5% |
| Noise Level | <35dB |
| Warranty | 5 years |
| Phase Selection | Single-phase/Three-phase |
| Inverter Options | 8/10/12/15 KW |
| Inverter Voltage Range | 125~600VA |
| Grid Voltage Range | 360~440V |
| PV Input Power | 4KW |
| Max PV Charge Current | 80A |
| AC Charge Current | 60A |
| Rated Output Power | 10KW |
| Max DC Input Voltage | 1000V |
| MPPT Work Voltage Range | 125~850V |
| Start Voltage | 125V |
| Rated Output Voltage | 400V, 3W+N+PE |
| Rated Frequency | 50Hz/60Hz |
| Inverter Dimensions | 600×400×850mm |
| Inverter Weight | 75.6KG |
| Battery Module Dimensions | 600×400×200mm |
| Battery Module Weight | 46.9KG |
| Base Dimensions | 600×400×55mm |
| Base Weight | 10.8KG |
Hunan Pinsheng Energy Technology Co., LTD located in Changsha City, Hunan Province, focuses on developing and producing Li-ion battery and battery system integration. Through years of development and research, we have formed a complete industry chain from research, production to sales. Our lithium ion batteries feature longer cycle life, higher security and reliability, higher energy density and other superior performance. Products are widely used in electric bikes, E-scooters, electric motorcycles, electric tricycles, golf carts, forklifts, electric vehicles, UPS, telecommunication systems, off-grid wind & solar energy storage, and more. Pinsheng Energy Battery products sell well at home and abroad, with strict quality guarantee systems to ensure high-quality products. We prioritize customers' needs and continuously improve product quality and services. With our own R&D team, customized products are available. Pinsheng Energy has become a competitive manufacturer in China, dedicated to being a top OEM & ODM manufacturer.
Packaging: Carton Package, Wooden Case
