Place of Origin:
HUNAN
Brand Name:
Pinsheng
Model Number:
PE-S10
Document:
High-performance lithium-ion rechargeable battery system designed for solar generators and portable power applications.
| Performance Parameters | 10KW | 15KW | 20KW | 25KW |
|---|---|---|---|---|
| Output Power | 10KW | 15KW | 20KW | 25KW |
| Phase | Simplex | Simplex | Simplex | Simplex |
| Maximum Output Power | 3KW/4KW/5KW optional | 3KW-5KW optional | 3KW-5KW optional | 3KW-5KW optional |
| Rated Voltage | 51.2V | 51.2V | 51.2V | 51.2V |
| Rated Capacity | 200AH | 300AH | 400AH | 500AH |
| Continuous Discharge Current | 100A | 100A | 100A | 100A |
| Peak Maximum Discharge Current | 110A/10S | 110A/10S | 110A/10S | 110A/10S |
| Standard Charging Current | 50A | 50A | 50A | 50A |
| Fast Charge Current | 100A | 100A | 100A | 100A |
| Number of Expandable Batteries | 2~15 | 3-15 | 4-15 | 5-15 |
| Optional Capacity Range | 10.24~76.8KWH | 15.36-76.8KWH | 20.48-76.8KWH | 25.6-76.8KWH |
| Cooling Method | Self-cooling | Self-cooling | Self-cooling | Self-cooling |
| Battery Type | Lithium Iron Phosphate | Lithium Iron Phosphate | Lithium Iron Phosphate | Lithium Iron Phosphate |
| Design Life | >15 years@25℃ | >15 years@25℃ | >15 years@25℃ | >15 years@25℃ |
| Cycle Life | ≈10000 times | ≈10000 times | ≈10000 times | ≈10000 times |
| Frequency | 50HZ/60HZ auto detect | 50HZ/60HZ auto detect | 50HZ/60HZ auto detect | 50HZ/60HZ auto detect |
| Grid Voltage Range | 230V(170Vac~280Vac) ±2% 110V(90Vac-280Vac)±2% | 230V(170Vac~280Vac) ±2% 110V(90Vac-280Vac)±2% | 230V(170Vac~280Vac) ±2% 110V(90Vac-280Vac)±2% | 230V(170Vac~280Vac) ±2% 110V(90Vac-280Vac)±2% |
| PV Maximum Input Power | 4200W | 4200W | 4200W | 4200W |
| MPPT Voltage Range | 60-115Vdc | 60-115Vdc | 60-115Vdc | 60-115Vdc |
| Charging & Discharging Efficiency | >92% | >92% | >92% | >92% |
| Battery Voltage Range | 40.0Vdc~60Vdc ± 0.6Vdc | 40.0Vdc~60Vdc ± 0.6Vdc | 40.0Vdc~60Vdc ± 0.6Vdc | 40.0Vdc~60Vdc ± 0.6Vdc |
| Warranty | Battery (10 years) Inverter (5 years) | Battery (10 years) Inverter (5 years) | Battery (10 years) Inverter (5 years) | Battery (10 years) Inverter (5 years) |
| Inverter Size/Weight | 602*403*319mm/15KG | 602*403*139mm/15KG | 602*403*139mm/15KG | 602*403*139mm/15KG |
| Battery Size/Weight | 602*403*200mm/55KG(single layer) | 602*403*200mm/55KG(single layer) | 602*403*200mm/55KG(single layer) | 602*403*200mm/55KG(single layer) |
| Chassis Size/Weight | 602*403*82mm/6KG | 602*403*82mm/6KG | 602*403*82mm/6KG | 602*403*82mm/6KG |
| Installation Method | Stacked | Stacked | Stacked | Stacked |
Note: Battery voltage range settings including under voltage alarm, shutdown voltage, over voltage alarm, and over voltage recovery can be configured via the LCD screen.
Available in Carton Package or Wooden Case for secure shipping and handling.
Hunan Pinsheng Energy Technology Co., LTD is located in Changsha City, Hunan Province. We specialize in developing and producing Li-ion batteries and battery system integration. Through years of development and research, we have formed a complete industry chain from research and production to sales.
Our lithium-ion batteries feature longer cycle life, enhanced security, superior reliability, higher energy density, and other exceptional performance characteristics. Our products are widely used in electric bikes, E-scooters, electric motorcycles, electric tricycles, golf carts, forklifts, electric vehicles, UPS systems, telecommunication systems, and off-grid wind & solar energy storage applications.
Pinsheng Energy Battery products sell well both domestically and internationally. We maintain strict quality assurance systems to ensure high-quality products. We prioritize customers' needs and value their suggestions, continuously improving our product quality and services.
With our own R&D team, we offer customized product solutions. Pinsheng Energy has become a competitive manufacturer in China, dedicated to becoming a top OEM & ODM manufacturer in the industry.
