Name: Pinsheng 2023 48v High Voltage 120kwh 130kwh 140kwh 145kwh 150kwh 160kwh 60 kw High Voltage Solar Lithium Lifipo4 Battery
Brand: Hunan Pinsheng Energy Technology Co., LTD.
SKU: PE-S10
Price: 6.00 USD
Availability: InStock

Home > Products > Energy Storage Lithium Battery >

Pinsheng 2023 48v High Voltage 120kwh 130kwh 140kwh 145kwh 150kwh 160kwh 60 kw High Voltage Solar Lithium Lifipo4 Battery

48v high voltage solar battery

lifepo4 energy storage battery

150kwh lithium battery with warranty

Place of Origin:

HUNAN

Brand Name:

Pinsheng

Model Number:

PE-S10

Document:

Product Brochure PDF

Request A Quote

Pinsheng 2023 48v High Voltage 120kwh 130kwh 140kwh 145kwh 150kwh 160kwh 60 kw High Voltage Solar Lithium Lifipo4 Battery

Product Details

Max Load Quantity(cells):

Battery Type:

Semi-solid State

Cycle Life:

6000 Cycles

Dimension (L*W*H):

1050*600*420

Application:

Home Appliances, Electric Power Systems, Solar Energy Storage Systems

Weight:

Customize

Operating Temperature(℃):

-20-60

Cathode Materials:

LiFePO4

Battery Type:

Lifepo4/lithium Battery

Voltage:

48V/51.2V

Capacity:

50ah 100ah Etc

Cycle Life:

6000 Times

Size:

Customized Flexible Size

Apllication:

Household Energy Storage

Protection:

Built-in Smart BMS

OEM/ODM:

Accepatable

MOQ:

1 Pcs

Warranty:

10YEARS

Payment & Shipping Terms

Minimum Order Quantity

Price

CN¥6,158.16-6,648.01

Solar Energy Storage With Long Cycle Life Power System 48v/51.2V 768v 512v 50ah 100ah 400ah 20kwh Stacked Lifepo4 Battery

Get Best Price

Wholesale Price Solar 48v 5120wh 10kwh ess All in One Stackable Lithium Battery Includes Inverter Home Energy Storage System

Get Best Price

PINSHENG Wholesale Lifepo4 5kw Camping Tragbare Powerstation Solar Generator Waterproof Portable Power Station 5000w Industry

Get Best Price

Factory 5kw Camping Tragbare Power Station Lifepo4 Battery Portable Solar Generator Industry Waterproof Powerstation 5000w

Get Best Price

15616151876

info@pinshengenergy.com

Contact Now

Product Description

Pinsheng 2023 48V High Voltage Solar Lithium LiFePO4 Battery

Product Overview

High-performance 48V lithium iron phosphate battery system designed for solar energy storage applications, available in multiple capacity configurations from 120kWh to 160kWh with 60kW power output.

Technical Specifications

Performance Parameters	10KW Model	15KW Model	20KW Model	25KW Model
Output Power	10KW	15KW	20KW	25KW
Phase	Simplex	Simplex	Simplex	Simplex
Maximum Output Power	3KW/4KW/5KW optional	3KW-5KW optional	3KW-5KW optional	3KW-5KW optional
Rated Voltage	51.2V	51.2V	51.2V	51.2V
Rated Capacity	200AH	300AH	400AH	500AH
Continuous Discharge Current	100A	100A	100A	100A
Peak Maximum Discharge Current	110A/10S	110A/10S	110A/10S	110A/10S
Standard Charging Current	50A	50A	50A	50A
Fast Charge Current	100A	100A	100A	100A
Number of Expandable Batteries	2~15	3-15	4-15	5-15
Optional Capacity Range	10.24~76.8KWH	15.36-76.8KWH	20.48-76.8KWH	25.6-76.8KWH
Cooling Method	Self-cooling	Self-cooling	Self-cooling	Self-cooling
Battery Type	Lithium Iron Phosphate	Lithium Iron Phosphate	Lithium Iron Phosphate	Lithium Iron Phosphate
Design Life	＞15 years@25℃	＞15 years@25℃	＞15 years@25℃	＞15 years@25℃
Cycle Life	≈10000 times	≈10000 times	≈10000 times	≈10000 times
Grid Voltage Range	230V(170Vac~280Vac) ±2% 110V(90Vac-280Vac)±2%	230V(170Vac~280Vac) ±2% 110V(90Vac-280Vac)±2%	230V(170Vac~280Vac) ±2% 110V(90Vac-280Vac)±2%	230V(170Vac~280Vac) ±2% 110V(90Vac-280Vac)±2%
PV Maximum Input Power	4200W	4200W	4200W	4200W
MPPT Voltage Range	60-115Vdc	60-115Vdc	60-115Vdc	60-115Vdc
Charging/Discharging Efficiency	>92%	>92%	>92%	>92%
Battery Voltage Range	40.0Vdc~60Vdc ± 0.6Vdc	40.0Vdc~60Vdc ± 0.6Vdc	40.0Vdc~60Vdc ± 0.6Vdc	40.0Vdc~60Vdc ± 0.6Vdc
Warranty	Battery (10 years) Inverter (5 years)	Battery (10 years) Inverter (5 years)	Battery (10 years) Inverter (5 years)	Battery (10 years) Inverter (5 years)
Inverter Size/Weight	602403319mm/15KG	602403139mm/15KG	602403139mm/15KG	602403139mm/15KG
Battery Size/Weight	602403200mm/55KG（single layer）	602403200mm/55KG（single layer）	602403200mm/55KG（single layer）	602403200mm/55KG（single layer）
Chassis Size/Weight	60240382mm/6KG	60240382mm/6KG	60240382mm/6KG	60240382mm/6KG
Installation Method	Stacked	Stacked	Stacked	Stacked

Key Features

High voltage 48V system with multiple capacity options (120kWh - 160kWh)
Lithium Iron Phosphate (LiFePO4) chemistry for enhanced safety and longevity
Expandable battery system supporting 2-15 units
High efficiency charging and discharging (>92%)
Long design life exceeding 15 years at 25℃
Excellent cycle life of approximately 10,000 cycles
Self-cooling technology for reliable operation
LCD screen for customizable voltage settings and monitoring

Certifications & Standards

Product Certifications: CE, UN38.3, MSDS, Shipping, Dangerous Package

Cell Certifications: CE, UL, IEC 62109-1&-2, IEC 62477, EN61000, UN38.3

Packaging: Carton Package, Wooden Case

Company Profile

Hunan Pinsheng Energy Technology Co., LTD located in Changsha City, Hunan Province, specializes in developing and producing Li-ion batteries and battery system integration. Through years of development and research, we have formed a complete industry chain from research, production to sales.

Our lithium-ion batteries feature longer cycle life, enhanced security, higher reliability, superior energy density, and other performance advantages. Products are widely used in electric bikes, E-scooters, electric motorcycles, electric tricycles, golf carts, forklifts, electric vehicles, UPS systems, telecommunication systems, and off-grid wind & solar energy storage applications.

Pinsheng Energy Battery products sell well both domestically and internationally, supported by a strict quality guarantee system. We prioritize customer needs and continuously improve product quality and services. With our own R&D team, we offer customized product solutions and are dedicated to becoming a top OEM & ODM manufacturer in China.
