Name: New Design Supply Commercial 5kw 10kw Complete Kit With bluetooth Hybrid Inverter Solar Energy Storage System 51.2V Lithium Batt
Brand: Hunan Pinsheng Energy Technology Co., LTD.
SKU: PS3K-5KWH-S
Price: 233.00 USD
Availability: InStock

Home > Products > Energy Storage Lithium Battery >

New Design Supply Commercial 5kw 10kw Complete Kit With bluetooth Hybrid Inverter Solar Energy Storage System 51.2V Lithium Batt

5kw solar energy storage system

10kw hybrid inverter with bluetooth

51.2V lithium battery with warranty

Place of Origin:

Hunan, China

Brand Name:

Pinsheng

Model Number:

PS3K-5KWH-S

Document:

Product Brochure PDF

Request A Quote

New Design Supply Commercial 5kw 10kw Complete Kit With bluetooth Hybrid Inverter Solar Energy Storage System 51.2V Lithium Batt

Product Details

Battery Type:

LiFePO4

Output Power Range:

5~10 KWh

Dimension (L*W*H):

620*438*190mm

Weight:

6.2KG-10.8KG

System Type:

Stackable

Type:

All-In-One

Communication Port:

CAN, Rs485

Protection Class:

IP20

Grid Connection:

Off Grid, Hybrid Grid

Model:

PS5000

Inverter Output:

5000 W

Rated Output Power:

10,000 VA

Battery Type:

Lithium Ion Battery

Max Input Power:

4400 W

Max Input Current:

50A

Protection Grade:

IP20

Noise:

<60dB

Communication Series:

RS485

External Module:

Wi-Fi

Payment & Shipping Terms

Minimum Order Quantity

Price

CN¥7,459.77

Solar Energy Storage With Long Cycle Life Power System 48v/51.2V 768v 512v 50ah 100ah 400ah 20kwh Stacked Lifepo4 Battery

Get Best Price

Wholesale Price Solar 48v 5120wh 10kwh ess All in One Stackable Lithium Battery Includes Inverter Home Energy Storage System

Get Best Price

PINSHENG Wholesale Lifepo4 5kw Camping Tragbare Powerstation Solar Generator Waterproof Portable Power Station 5000w Industry

Get Best Price

Factory 5kw Camping Tragbare Power Station Lifepo4 Battery Portable Solar Generator Industry Waterproof Powerstation 5000w

Get Best Price

15616151876

info@pinshengenergy.com

Contact Now

Product Description

New Design Supply Commercial 5kw 10kw Complete Kit With Bluetooth Hybrid Inverter Solar Energy Storage System 51.2V Lithium Battery

Complete solar energy storage system featuring a hybrid inverter with Bluetooth connectivity and 51.2V lithium battery technology.

Technical Specifications

Model	PS5K	PS3K
Inverter output	5,000W	3,000W
Rated output power	10,000VA	6,000VA
Rated output voltage	230Vac(L/N/PE single-phase)	230Vac(L/N/PE single-phase)
Load bearing motor capacity	4HP	2HP
Rated frequency	50Hz/60Hz	50Hz/60Hz
Output waveform	Pure sine wave	Pure sine wave
Switching time	10ms (Typical value)	10ms (Typical value)
Battery type	Lithium Ion Battery	Lithium Ion Battery
Rated battery voltage	48Vdc	48Vdc
Voltage range	40~60Vdc	40~60Vdc
Max PV charging current	80A	60A
Max mains/generator charging current	60A	60A
Max mixed charging current	140A	120A
MPPT paths	1	1
Max Input Power	4,400W	3,400W
Max input current	50A	40A
Max open circuit voltage	145Vdc	145Vdc
MPPT operating voltage range	60~115Vdc	60~115Vdc
Input voltage range	UPS mode: 170~280Vac APL mode: 90~280Vac	UPS mode: 170~280Vac APL mode: 90~280Vac
Input frequency range	50Hz/60Hz	50Hz/60Hz
Bypass overload current	40A	30A
MPPT tracking efficiency	99.90%	99.90%
Max efficiency of battery inverter	92%	92%
Size	620438190mm	620438190mm
Weight	10.8kg	6.2kg
Protection grade	Indoor use	Indoor use
Ambient temperature	-15℃~55℃	-15℃~55℃
Noise	<60dB	<60dB
Cooling method	Intelligent air cooling	Intelligent air cooling
Built-in interface	RS485	RS485
External module	Wi-Fi	Wi-Fi

Company Profile

Hunan Pinsheng Energy Technology Co., Ltd. is located in Changsha City, Hunan Province. We focus on developing and producing Li-ion batteries and battery system integration. Through years of development and research, we have formed a complete industry chain from research and production to sales.

Our lithium-ion batteries feature longer cycle life, higher security and reliability, higher energy density, and superior performance. Products are widely used in electric bikes, e-scooters, electric motorcycles, electric tricycles, golf carts, forklifts, electric vehicles, UPS systems, telecommunication systems, off-grid wind & solar energy storage, and more.

Pinsheng Energy Battery products sell well both domestically and internationally. We maintain strict quality assurance systems to ensure high-quality products. We prioritize customer needs and continuously improve our product quality and services. With our own R&D team, we can accommodate custom product requirements. Pinsheng Energy has become a competitive manufacturer in China, dedicated to being a top OEM & ODM manufacturer.

Product Parameters

Packaging & Delivery

Packaging includes wooden carton and wooden pallet. The packaging can be designed according to your specific requirements.

Frequently Asked Questions

Who are we?
We are based in Hunan, China, established in 2021. We sell to South America (25.00%), North America (20.00%), Northern Europe (20.00%), Southern Europe (15.00%), Domestic Market (10.00%), and Mid East (10.00%). Our office employs 11-50 people.
How can we guarantee quality?
We always provide a pre-production sample before mass production and conduct final inspection before shipment.
What can you buy from us?
Lithium Battery, Lithium Battery Pack, Solar Energy Storage Lithium Battery, Electric Vehicle Battery, Solar System
Why should you buy from us instead of other suppliers?
1. We focus on lithium battery manufacturing for more than 13 years
2. We have advanced facilities and strong R&D strength
3. Our batteries feature longer cycle life, higher security and reliability, and higher energy density
4. We maintain strict quality guarantee systems
What services can we provide?
Accepted Delivery Terms: FOB, CFR, CIF, EXW, FAS, CIP, FCA, DDP, DDU
Accepted Payment Currency: USD, CNY
Accepted Payment Type: T/T, L/C, MoneyGram, Credit Card, PayPal, Western Union, Cash, Escrow
Languages Spoken: English, Chinese
