Place of Origin:
Hunan, China
Brand Name:
PE
Certification:
CE/RoHS/UN38.3/MSDS
Model Number:
PE24100
Document:
Item
|
Detail
|
Battery Type
|
LiFePO4
|
Capacity
|
100Ah, 2560Wh @C2, 25℃
|
Nominal Voltage
|
25.6V DC
|
Operating Voltage Range
|
20V DC-28.8V DC
|
BMS
|
Smart BMS
|
Cycle Life @ 100% DOD
|
>3000 Cycles(100% DOD @C2, 25℃)
|
Cycle Life @ 80% DOD
|
>4000 Cycles(80% DOD @C2, 25℃)
|
Cycle Life @ 70% DOD
|
>5000 Cycles(70% DOD @C2, 25℃)
|
Dimensions
|
528mm(L)x238mm(W)x218mm(T)
|
Serialization
|
8S1P
|
Battery Box Material
|
Cold-rolled Steel Sheet
|
Weight
|
24kg
|
Charge Current
|
100A Continuous
|
Discharge Current
|
100A Continous
|
Charging Shut-off Voltage
|
28.8V
|
Discharging Limit Voltage
|
20V
|
Over-current Protection
|
250A, 10s Delay
|
Short Circuit Protection
|
500A, ≤300 us Delay
|
Charging Under/Over Temp Protection
|
0℃/55℃
|
Charging under/over Temp Protection
|
-20℃/60℃
|
Balance Current
|
≤200mA
|
Self-Discharge Rate
|
<3% Per Month
|
