Pinsheng 12.8v 24v 48v 100ah 50ah 200ah 150ah solar power batteries battery lithium

Pinsheng 12.8v 24v 48v 100ah 50ah 200ah 150ah solar power batteries battery lithium

24v solar power batteries

48v solar power batteries

12.8v solar power batteries

Place of Origin:

Hunan, China

Brand Name:

Pinsheng

Model Number:

PE24200

Contact Us
Request A Quote
Product Details
Features:
Long Cycle Life
Battery Type:
Lithium Ion, LiFePO4, Other
Product Name:
Lithium Iron Phosphate Lifepo4 Battery
Capacity:
50Ah 100Ah 150Ah 200Ah
Voltage:
12V 24v 48v
Protection:
BMS Protection
Size:
Customized Flexible Size
Cycle Life:
6000 Times
Discharge Current:
0.2C-1C(accept OEM)
Apllication:
Energy Store
Keywords:
Rechargeble Lipo Battery
Port:
Shenzhen Shanghai Quanzhou Ningbo
Payment & Shipping Terms
Minimum Order Quantity
2 pieces
Price
$288.00/pieces 2-9 pieces
Packaging Details
One Battery One Wooden Case
Supply Ability
3000 Unit/Units per Month
Product Description
Product Description
Pinsheng 12.8v 24v 48v 100ah 50ah 200ah 150ah solar power batteries battery lithium 0
Pinsheng 12.8v 24v 48v 100ah 50ah 200ah 150ah solar power batteries battery lithium 1
Pinsheng 12.8v 24v 48v 100ah 50ah 200ah 150ah solar power batteries battery lithium 2
Pinsheng 12.8v 24v 48v 100ah 50ah 200ah 150ah solar power batteries battery lithium 3
Pinsheng 12.8v 24v 48v 100ah 50ah 200ah 150ah solar power batteries battery lithium 4
Specification
temsItems
Parameter
Battery Type
LiFePO4
Nominal Voltage
12.8V
Nominal Capacity
100Ah
Energy
1.28KWh
Internal Resistance
≤20mΩ
Series & Parallel Application
up to 4 series 4 parallel connected application
Limited Charge Voltage
14.6±0.2V
Floating Charge Voltage
13.8±0.2V
Charge Method
CC/CV
Discharge Cut-off Voltage
10.0V
Standard Charge Current
60A
Max. Charge Current
80A
Standard Continuous Discharge Current
80A
Max. Continuous Discharge Current (<30min)
100A
Pulse Discharge Current (<3s)
350A
Cycle Life
> 5000 cycles
Dimension (mm)
Length: 323±2 Width: 171±2 Height: 232±2
Weight
12.8±0.2Kg
Charge Temperature Range
0~45°C
Discharge Temperature Range
-20~60°C
Recommended Operating Temperature
15~35°C
Self-Discharge Rate (Residual capacity)
≤3%/month; ≤15%/years
Self-Discharge Rate (Reversible capacity)
≤2%/month; ≤8%/years
Storage Temperature & Humidity Range (Less than 1 month)
-20~35°C, 45~75%RH
Storage Temperature & Humidity Range (Less than 3 months)
-10~35°C, 45~75%RH
Recommended Storage Temperature & Humidity Range
15~35°C,45~75%RH
Packing & Delivery
Pinsheng 12.8v 24v 48v 100ah 50ah 200ah 150ah solar power batteries battery lithium 5
Pinsheng 12.8v 24v 48v 100ah 50ah 200ah 150ah solar power batteries battery lithium 6
One Battery One Wooden Case
Pinsheng 12.8v 24v 48v 100ah 50ah 200ah 150ah solar power batteries battery lithium 7
Company Profile
Pinsheng 12.8v 24v 48v 100ah 50ah 200ah 150ah solar power batteries battery lithium 8
Pinsheng 12.8v 24v 48v 100ah 50ah 200ah 150ah solar power batteries battery lithium 9
Pinsheng 12.8v 24v 48v 100ah 50ah 200ah 150ah solar power batteries battery lithium 10
Pinsheng 12.8v 24v 48v 100ah 50ah 200ah 150ah solar power batteries battery lithium 11
Pinsheng 12.8v 24v 48v 100ah 50ah 200ah 150ah solar power batteries battery lithium 12
Pinsheng Energy with R&D located in Changsha City, Hunan Province, near to Guangzhou. It is a High-Tech Enterprise with 4,000 square meters workshop and 121 staffs. Pinsheng Energyh focus on developing and producing Lithium battery and battery system integration, after many years development and research, we have formed a complete industry chain from research, production to sales. Our lithium battery has the characteristics of longer cycle life, more higher security and more reliability, higher energy density and other superior performance. Our products are widely used in energy storage system such as off grid wind & solar energy storage, telecommunication system, UPS and etc and power system such as electric motorcycles, electric bikes, E- scooter, electric tricycles, golf cart, fork lift,electric vehiclesetc. Pinsheng Energy Battery products has a good reputation in China and abroad, it has strict quality guarantee system to ensure high-quality products. Pinsheng Energy put customers' needs at the first and listen to their suggestions. We will continuously improve our product quality and services. Pinsheng Energy is edicated to be a top OEM &ODM lithium battery manufacturer in the world.
