Place of Origin:
Hunan, China
Brand Name:
PE
Certification:
CE
Model Number:
PE12200
Document:
item | value |
Warranty | 5years |
Anode Material | LFP |
Chargeable | Yes |
Application | Home Appliances, BOATS, Golf Carts, SUBMARINES, Electric Bicycles/Scooters, Electric Folklifts, electric vehicles, Electric Wheelchairs, Electric Power Systems, Solar Energy Storage Systems, Uninterruptible Power Supplies, Electric Forklifts |
Brand Name | PE |
Certification | ce |
Model Number | PE12200 |
Place of Origin | China |
Hunan | |
Weight | 22KG |
The charging ratio | 0.5C |
The discharge rate | 0.5C |
Storage Type | LiFePO4 Battery |
Dimensions | 520mm(L)x218mm(W)x173mm(T) |
Serialization | 4S1P |
Battery Box Material | Cold-rolled Steel Sheet |
Charging Shut-off Voltage | 14.4V |
Discharging Limit Voltage | 10V |
Over-current Protection | 220A, 10s Delay |
Short Circuit Protection | 500A, ≤300 us Delay |
Charging Under/Over Temp Protection | 0℃/55℃ |
Charging under/over Temp Protection | -20℃/60℃ |
Balance Current | ≤200mA |
