All in one Home Solar ESS Cabinet 51.2V 100Ah 200Ah 300Ah 400Ah 500Ah

All in one Home Solar ESS Cabinet 51.2V 100Ah 200Ah 300Ah 400Ah 500Ah

100Ah Home Solar ESS Cabinet

51.2V Home Solar ESS Cabinet

200Ah Home Solar ESS Cabinet

Place of Origin:

Hunan, China

Brand Name:

PE

Certification:

MSDS,UN38.3,CE,FCC

Model Number:

PE48300

Contact Us
Request A Quote
Product Details
Battery Size:
LifePO4
Weight:
150Kg
The Charging Ratio:
1C
The Discharge Rate:
1C
Storage Type:
Dry, Cool And Ventilation
Anode Material:
LFP
Application:
Home Appliances, BOATS, Golf Carts, Electric Bicycles/Scooters, Electric Wheelchairs, Solar Energy Storage Systems, Uninterruptible Power Supplies
Cycle Life:
6000 Times
Serialization:
16S1P/2P/3P/4P/5P
Inverter:
3KW/5KW/ 10KW
Battery Box Material:
Aluminum Alloy
Warranty:
10YEARS
Chargeable:
Yes
Port:
Shenzhen
Payment & Shipping Terms
Minimum Order Quantity
2 sets
Price
$5,422.00/sets 2-9 sets
Supply Ability
20 Set/Sets per Month
Product Description
Product Description
All in one Home Solar ESS Cabinet 51.2V 100Ah 200Ah 300Ah 400Ah 500Ah 0
All in one Home Solar ESS Cabinet 51.2V 100Ah 200Ah 300Ah 400Ah 500Ah 1
All in one Home Solar ESS Cabinet 51.2V 100Ah 200Ah 300Ah 400Ah 500Ah 2
All in one Home Solar ESS Cabinet 51.2V 100Ah 200Ah 300Ah 400Ah 500Ah 3
All in one Home Solar ESS Cabinet 51.2V 100Ah 200Ah 300Ah 400Ah 500Ah 4
All in one Home Solar ESS Cabinet 51.2V 100Ah 200Ah 300Ah 400Ah 500Ah 5
Specification
Item
Detail
Battery Cell
A Grade Prismatic Li FePO4 3.2V 100Ah
Nominal Voltage
100Ah /200Ah/300Ah/400Ah/500Ah
Cycle Life
>6000 Cycles(@C2, 25 )
Dimensions
1100/ 1300/ 1500/ 1700/ 1900mm(H)x640mm(W)
x400mm(T)
Serialization
16S1P/2P/3P/4P/5P
Inverter
3KW/5KW/ 10KW
Battery Box Material
Aluminum Alloy
Weight
105/ 165/225/285/345kgs
Charge Current
50A/ 100A/200A/400A Continuous
Discharge Current
50A/ 100A/200A/400A Continous
Charging Shut- off Voltage
58.8V
Discharging Limit Voltage
37V
Communication
RS232/ RS485/CAN
Software
APP
Short Circuit Protection
1000A, ≤ 300 us Delay
Charging Under/ Over Temp Protection
0°C /55°C
Charging under/ over Temp Protection
-20 /60
Self- Discharge Rate
<3% Per Month
Warning
To prevent battery leakage, heat, and fire, please take the following
precautions:
* Do not immerse the battery in seawater or water.
* Do not use the battery near hot and high temperature sources, such as

fire and heater
* Do not use batteries by reversing positive and negative electrodes
* Do not connect the battery directly to the power socket
* Do not transport or store batteries with metal, such as hair clips and necklaces.
* Do not knock or throw, trample battery.
* Do not fall, impact or bend the battery
* Battery case design and packaging do not damage the battery
* Do not remove the battery under any circumstances
* Replacement of cell should be completed by cell supplier or equipment supplier, users are not allowed to replace.
* Do not use in the place of strong static electricity and magnetic field, otherwise it is easy to damage the battery safety protection device, bringing the hidden danger of insecurity.
* If the battery has any odor, heat, discoloration, deformation or any abnormal phenomenon during use, storage and charging, immediately remove the battery from the device or charger and stop using it.
* If the battery is dirty, wipe it with dry cloth before use, otherwise it may lead to poor contact function failure.
* Do not use or install the battery under high temperature (direct sunlight or very hot car), otherwise the battery may overheat, fire or function failure, shorten the life of the battery.
* Used batteries should be covered with insulating paper to prevent fire and explosion.
All in one Home Solar ESS Cabinet 51.2V 100Ah 200Ah 300Ah 400Ah 500Ah 6
All in one Home Solar ESS Cabinet 51.2V 100Ah 200Ah 300Ah 400Ah 500Ah 7
All in one Home Solar ESS Cabinet 51.2V 100Ah 200Ah 300Ah 400Ah 500Ah 8
All in one Home Solar ESS Cabinet 51.2V 100Ah 200Ah 300Ah 400Ah 500Ah 9
All in one Home Solar ESS Cabinet 51.2V 100Ah 200Ah 300Ah 400Ah 500Ah 10
All in one Home Solar ESS Cabinet 51.2V 100Ah 200Ah 300Ah 400Ah 500Ah 11
Advantage:
/ / Lithium iron phosphate batteries, more efficient and safe.
/ / Millisecond switching, support UPS and 2 4 - hour uninterrupted power supply.
/ / Full power continuous output, instantaneous power up to 2 times the rated power.
/ / Up to 3 inverters in Parallel, plug and play design, no professional installation required.
/ / Modular stacking, flexible configuration of energy storage units, power expansion on demand.
/ / EMS cloud platform data acquisition. Intermittent transmission, easy to achieve Intelligent
interconnection.
Packing & Delivery
All in one Home Solar ESS Cabinet 51.2V 100Ah 200Ah 300Ah 400Ah 500Ah 12
All in one Home Solar ESS Cabinet 51.2V 100Ah 200Ah 300Ah 400Ah 500Ah 13
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
Company Profile
All in one Home Solar ESS Cabinet 51.2V 100Ah 200Ah 300Ah 400Ah 500Ah 14
All in one Home Solar ESS Cabinet 51.2V 100Ah 200Ah 300Ah 400Ah 500Ah 15
All in one Home Solar ESS Cabinet 51.2V 100Ah 200Ah 300Ah 400Ah 500Ah 16
Pinsheng Energy with R&D located in Changsha City, Hunan Province, near to Guangzhou. It is a High-Tech Enterprise with 4,000 square meters workshop and 121 staffs. Pinsheng Energy focus on developing and producing Lithium battery and battery system integration, after many years development and research, we have formed a complete industry chain from research, production to sales. Our lithium battery has the characteristics of longer cycle life, more higher security and more reliability, higher energy density and other superior performance. Our products are widely used in energy storage system such as off grid wind & solar energy storage, telecommunication system, UPS and etc and power system such as electric motorcycles, electric bikes, E- scooter, electric tricycles, golf cart, fork lift,electric vehicle setc. Pinsheng Energy Battery products has a good reputation in China and abroad, it has strict quality guarantee system to ensure high-quality products. Pinsheng Energy put customers' needs at the first and listen to their suggestions. We will continuously improve our product quality and services. Pinsheng Energy is dedicated to be a top OEM &ODM lithium battery manufacturer in the world.
