Name: High Effciency LifePO4 Lithium Battery Lightweight 264mm X 164mm X 64mm
Brand: Hunan Pinsheng Energy Technology Co., LTD.
SKU: HY00085
Price: 3,841.00 USD
Availability: InStock

Home > products > LifePO4 Lithium Battery >

High Effciency LifePO4 Lithium Battery Lightweight 264mm X 164mm X 64mm

lithium iron phosphate battery

lifepo4 rechargeable battery

Place of Origin:

Changsha, China

Brand Name:

HYZZ

Certification:

ISO9001, CE, CB, UN38.3

Model Number:

HY00085

Document:

Product Brochure PDF

Request A Quote

High Effciency LifePO4 Lithium Battery Lightweight 264mm X 164mm X 64mm

Product Details

Name:

LifePO4 Lithium Battery

Model:

24V 20Ah

L X W X H:

264mmX164mmx64mm

Application:

Wheelchairs And Scooters

Charging:

0～45℃

Rated Discharge Current:

Payment & Shipping Terms

Packaging Details

foam, wooden box / foam, carton, tray

Delivery Time

22 days

Payment Terms

L/C, T/T

Supply Ability

10,000 PCS per month

Pinsheng Lithium Battery 15kWh 51.2V 280Ah 300Ah LiFePO4 Battery Pack Solar Energy Storage Battery for Home Use

Get Best Price

Video

Pinsheng Lithium Battery 15kWh 51.2V 280Ah 300Ah Home LiFePO4 Battery Pack Solar Energy Storage Battery

Get Best Price

Video

PINSHENG Lithium Battery 15kWh 51.2V 280Ah 300Ah Home LiFePO4 Battery Pack Solar Energy Storage Battery for Home Use

Get Best Price

Video

Pinsheng 51.2V 280Ah Solar Lithium Battery Pack 10kwh 14Kwh 15kwh Solar Energy System 48V 280Ah LiFePO4 Energy Storage Battery

Get Best Price

15616151876

info@pinshengenergy.com

Contact Now

Product Description

High Effciency LifePO4 Lithium Battery Lightweight 264mm X 164mm X 64mm

Model: 24V20Ah

Dimension: 264mmX164mmx64mm

Features: iron lithium 81160227/8S; charge cut-off voltage:29.2V; discharge cut-off voltage: 20V; working current:10A; weight:5.6KG

Key advantages
High energy density: more energy with less weight and footprint.
High charge currents (short charge period)
High discharge currents
Ultra-high cycling performance (up to six times the battery life of a conventional battery)
High effciency between charging and discharging
Higher continual power available
Wide operating temperature
Predictable end of life due BMS controller
The loweat possible TCO

Applications :
♦ Wheelchairs and scooters
♦ Solar/wind energy storage
♦ Back-up power for small UPS
♦ Golf trolleys & buggies
♦ Electric bikes

			Number	HY00085
			Version	A0
	HYLF/24/20-001 Battery pack specification		Date	2019-5-7
1．Basic characteristics			Product picture
Product name	Industrial lithium battery		Batteries:Lithium iron phosphate battery
product code	HYLF/24/20-001
L x W x H	264mmX164mmx64mm
Rated voltage	24VSeries structure
Rated Capacity	20Ah
Serialization	8S
Internal resistance	≤100mΩ
Discharge cutoff voltage	18.4V		Shell color □ Sub black □ Bright gray □ +Fruit green + bright gray two-color □ White+ black ☑ Blue thermoplastic film Charging and discharging interface □ Wall terminal □ Anderson □ Navigation plug ☑ Positive and negative lines □ Pole □ Hardware contact
Charging protection voltage	28.8V
Max.charging voltage	29.2V
Max. charging current	10A
Maximum discharge current	10A
Peak current	20±2 2S
Rated discharge current	5A
Charging method	CC/CV
weight	5.6Kg
Operating temperature	Charging	0～45℃
	Discharge	-20～55℃
60-80%SOC , 2 Storage temperature 60-80% SOC storage, need to recharge every 2 months	-10～35℃
C1 Cycle life Cycle life	1500 Times
price	RMB:¥ 00.00
Delivery period	25 Working day
