High Density 18650 Lithium Ion Battery 12V 30Ah Lifepo4 Automotive Battery
Model: 12V 30Ah
Dimension:280mmX135mmx120mm;
Feature:
Conversion time:5ms;Analog sine wave; AC input:AC110V~220V,DC input:DC18V-36V;Car input:12V,DC output:12V,USB 5V;Weight:3.5KG
Features
1. Different capacity battery cells for options.
2. Green product, long standby time, one year wrranty, excellent safety performance.
3. Short circuit testing passed, overcharge testing passed.
4. Best sale service and good price.
5. High capacity, high level platform, long working hours, long cycle life,
Application : widely used in li-ion battery, 18650 li-ion battery, polymer lithium battery,lifepo4 battery.
1) Communication device: communication base station, handheld road test instruments, portable communication tester, portable radio station.
2)Medical instruments: monitor, electrocardiogram machine, portable type-B ultrasonic, defibrillator, breathing machine.
3) Industrial instrument:water quality testing meter, geotechnical tester, laser orientation instrument car arrester.
4) Electric tools: handheld electric drill, moped, golf carts.
Warranty:
The period of warranty is one year from the date of shipment.
We guarantee to give a replacement in case of cells with defects proven due to manufacturing process instead of the customer abuse and misuse.
|
|
|
Number |
HY.NO007 |
| Version |
A0 |
|
HYLF/12/30-001
Battery pack specification
|
Date
|
2019-5-7
|
| 1．Basic characteristics |
Product picture
|
|
Product name
|
Portable power supply
|
Battery: ternary lithium battery
|
|
product code
|
HYLF/12/30-001 |
| L x W x H |
280mmX135mmx120mm |
| Rated voltage |
12VSeries structure |
| Rated Capacity |
30Ah |
| Serialization |
4S |
|
Internal resistance
|
≤100mΩ |
| Discharge cutoff voltage |
11.2V |
Shell color
□ Sub black
□ Bright gray
□ +Fruit green + bright gray two-color
□ White+ black
□ Blue thermoplastic film
Charging and discharging interface
□ Wall terminal
□ Anderson
□ Navigation plug
□ Positive and negative lines
□ Pole
□ Hardware contact
|
| Charging protection voltage |
16.8V |
|
Max.charging voltage
|
17V
|
|
Max. charging current
|
10A
|
|
Maximum discharge current
|
25A
|
|
Peak current
|
50±5 2S |
|
Rated discharge current
|
15A |
| Charging method |
CC/CV |
5ms,,AC110V~220V,DC18V-36V,12V,12V,USB 5V.Features: conversion time 5ms, analog sine wave, AC input AC110V~220V, DC input DC18V-36V, car 12V input, DC output 12V, USB 5V.
|
|
weight
|
3.5Kg |
|
Operating temperature
|
Charging
|
0～45℃ |
|
Discharge
|
-20～55℃ |
|
60-80%SOC , 2 Storage temperature 60-80% SOC storage, need to recharge every 2 months
|
-10～35℃
|
|
C1 Cycle life
Cycle life
|
1500 Times
|
| price |
RMB:¥ 00.00 |
|
Delivery period
|
25 Working day
|
FAQ
Q: Is OEM/ODM battery pack available?
A: Yes, OEM/ODM battery packs are warmly welcome. Professional engineers provide technical support.
Q: What information do you need to make a customized battery pack?
A: We need the details below:
1. Size of the battery pack you need in mm.
2. Capacity of the Battery pack.
3. Voltage of the battery pack.
4. Max discharge current.
5. Cable and connector types you need.
6. Casing and Terminals if required.
7. Any protection circuits you may need.
Q: Can you print my logo on the battery cover?
A: Yes, custom logo service and branding is available.
Q: Is sample order acceptable?
A: Yes, for most of the batteries, sample orders for testing quality is reasonable and acceptable.
